CHAOS-DI4 – 4 Channel Active DI Box (Professional Audio)
The CHAOS-DI4 is a high-performance 4-channel active DI box designed for professional live sound and
studio applications. Built in New Zealand, it delivers the clarity, reliability, and flexibility demanded by sound
engineers and musicians alike.
Key Features:
- 4 independent channels – ideal for stage and studio use
- Transparent performance: flat frequency response from 10Hz – 95kHz
- Ultra-low distortion: THD <0.008%
- Excellent signal clarity: 100dB signal-to-noise ratio
- Switchable -20dB pad on every channel for handling hot signals
- Ground lift switches to eliminate hum and noise issues
- Compact and durable design for professional use
Specifications:
- Input Impedance: 10MΩ
- Output Impedance: 100Ω
- Signal-to-Noise Ratio (SNR): 100dB
- Total Harmonic Distortion (THD): <0.008%
- Frequency Response: 10Hz – 95kHz (flat)
- Pad: -20dB (per channel)
- Ground Lift: Yes, on every channel
- Power: External 9–24V DC supply (not included)
- Dimensions: 150mm (L) x 100mm (W) x 46mm (H)
Warranty: Includes a 1-year limited warranty for peace of mind.
The CHAOS-DI4 is engineered for transparent audio performance, making it equally at home in professional
touring rigs, recording studios, or permanent installations.
Made in New Zealand – built with precision and quality.
